Description
Powered by Cummins 500KVA Generator Diesel Generators 500KVA Generador 400KW Generator
| Engine Model | KTA19-G3A |
| Number of Cylinders | 6 cylinders inline |
| Cycle | 4 stroke |
| Aspiration | Turbocharged and after water-cooled |
| Bore×Stroke | 159mm x159mm |
| Displacement | 19L |
| Compression ratio | 13.9:1 |
| Prime Power/Speed | 448KW / 1500rpm |
| Standby Power/Speed | 504KW / 1500rpm |
| Speed Governor | Electrical |
| Cooling System | Forced water cooling cycle |
| Steady speed droop | ≤1% |
| Total lubrication system capacity | 50L |
| Coolant capacity (engine only) | 30L |
| Fuel Consumption at 100% Load | 91L/h |
| Starter Motor | DC24V |
| Alternator | DC24V |
Alternator Spec
| Alternator Model | Stamford / Leroy Somer / Mecc-Alte / Wellpower |
| Standby power | 450KW/562.5KVA |
| Frequency/speed | 50HZ/1500rpm |
| Exciter type | Single bearing, Brushless, Self-excited |
| Power factor | 0.8 |
| Voltage adjust range | ≥5% |
| Voltage regulation NL-FL | ≤±1% |
| Insulation Grade | H |
| Protection Grade | IP23 |
| Phase |
Three phases |
|
Controller
|
||||
|
Optional Controller Brand
|
Smartgen/Deepsea/ComAp etc.
|
|||
