Description
|
Engine Spec： 6LTAA8.9-G3
|
|
|
Number of Cylinders
|
6 Cylinders
|
|
Cylinders arrangement
|
Vertical in line
|
|
Cycle
|
4 stroke
|
|
Aspiration
|
Turbocharged and after water cooled
|
|
Bore×Stroke
|
114mm*145mm
|
|
Displacement
|
8.9L
|
|
Compression ratio
|
16.6:1
|
|
Prime Power/Speed
|
224KW/1500rpm
|
|
Standby Power/Speed
|
248KW/1500rpm
|
|
Speed Governor
|
Electrical
|
|
Cooling System
|
Forced water cooling cycle
|
|
Steady speed droop
|
≤1%
|
|
Total lubrication system capacity
|
27.6L
|
|
Starter Motor
|
DC24V
|
|
Alternator
|
DC24V
|
|
Alternator Spec
|
|
|
Alternator brand
|
Stamford,Marathon,Leroy Somer,Mecc-alte
|
|
Prime power
|
280KVA
|
|
Frequency/speed
|
50HZ/1500rpm (60Hz/1800rpm)
|
|
Exciter type
|
Single bearing, Brushless, Self-excited
|
|
Power factor
|
0.8
|
|
Voltage adjust range
|
≥5%
|
|
Voltage regulation NL-FL
|
≤±1%
|
|
Insulation Grade
|
H
|
|
Protection Grade
|
IP23
|
|
Control Panel
|
|
|
Brand
|
Deepsea/SmartGen/ComAp
|
