Description
|
Engine Spec
|
|
|
Engine Model
|
6BTAA5.9-G2
|
|
Number of Cylinders
|
6 cylinders, Vertical in line
|
|
Cycle
|
4 stroke
|
|
Aspiration
|
Turbocharged and after water cooled
|
|
Bore×Stroke
|
102mm x120mm
|
|
Displacement
|
5.9L
|
|
Compression ratio
|
17.5:1
|
|
Prime Power/Speed
|
150kva / 1500rpm
|
|
Standby Power/Speed
|
130KW / 1500rpm
|
|
Speed Governor
|
electrical
|
|
Cooling System
|
Forced water cooling cycle
|
|
Steady speed droop
|
≤1%
|
|
Total lubrication system capacity
|
16.4L
|
|
Coolant capacity (engine only)
|
9.1L
|
|
Fuel Consumption at 100% Load
|
209g/kw.L
|
|
Starter Motor
|
DC24V,
|
|
Alternator
|
DC24V
|
|
Alternator Spec
|
|
|
Alternator brand
|
Stamford, Marathon, Leroy Somer, Mecc-alte, TWGII…
|
|
Prime power
|
150kva
|
|
Frequency/speed
|
50HZ/1500rpm (60Hz/1800rpm)
|
|
Exciter type
|
Single bearing, Brushless, Self-excited
|
|
Power factor
|
0.8
|
|
Voltage adjust range
|
≥5%
|
|
Voltage regulation NL-FL
|
≤±1%
|
|
Insulation Grade
|
H
|
|
Protection Grade
|
IP23
|
|
Phase
|
Three phases or Single phase
|
| Control Panel | |
| Optional brands | Deespea/Smartgen/ComAp |
