Description
| Cummins Engine Data | |
| Engine Model | 4BT3.9-G2 |
| Number of Cylinders | 4 cylinders |
| Aspiration | Turbocharged and after water cooled |
| Bore×Stroke |
102mm x120mm |
| Displacement | 3.9L |
| Prime Power/Speed | 40KW / 1500rpm |
| Standby Power/Speed | 45KW / 1500rpm |
| Speed Governor | electrical |
| Cooling System | Forced water cooling cycle |
| Fuel Consumption at 100% Load | 5.7l/h |
|
Alternator Data |
|
|
Optional brands |
Stamford/Leroy Somer/Marathon |
|
Prime power |
30KW |
|
Frequency/speed |
50Hz/1800rpm |
|
Exciter type |
Brushless, Self-excited |
|
Power factor |
0.8 |
|
Voltage adjust range |
≥5% |
|
Voltage regulation NL-FL |
≤±1% |
|
Insulation Grade |
H |
|
Protection Grade |
IP23 |
| Control Panel | |
| Optional brands | Deespea/Smartgen/ComAp |
